Product Summary

The AXK5F30347YJ is a narrow-pitch connector for board-to-board connection. The applications of the AXK5F30347YJ include Compact portable devices “Cellular phones, DVC, Digital cameras, etc”.

Parametrics

AXK5F30347YJ absolute maximum ratings: (1) Rated current: 0.5A/contact (Max. 10A at total contacts); (2) Rated voltage: 60V AC/DC; (3) Breakdown voltage: 150V AC for 1 min.; (4) Insulation resistance: Min. 1,000MΩ (initial); (5) Contact resistance: Max. 90mΩ; (6) Composite insertion force: Max. 0.981N/contacts×contacts (initial); (7)Composite removal force: Min. 0.0588N/contacts×contacts; (8) Contact holding force (Socket contact): Min. 0.981N/contacts; (9) Ambient temperature: -55℃ to +85℃; (10) Storage temperature: -55℃ to +85℃ (product only), -40℃ to +50℃ (emboss packing); (11) Insertion and removal life: 50 times; (12) Unit weight: 20-contact type: Socket: 0.06g Header: 0.04g.

Features

AXK5F30347YJ features: (1) The connector is a two-piece structure and 0.5mm pitch; (2) Strong resistance to adverse environments. Utilizes construction for high contact reliability; (3) Simple locking structure Superior mating operation with click feel to indicate that mating is complete; (4) Mating length 0.55mm; (5) The lower connector bottom surface construction prevents contact and shorts between the PCB and metal terminals; (6) Automatic mounting inspection is facilitated by the gull-wing terminal shape which makes mounting verification easy; (7) Connectors for inspection available.
