Product Summary

The G4W-2214P-US-HP-DC24V is a Power Relay.

Parametrics

G4W-2214P-US-HP-DC24V absolute maximum ratings: (1)Contact resistance: 30mΩ; (2)Operate time 20ms max. (mean value: approx. 13ms); (3)Release time 5ms max. (mean value: approx. 2.50ms); (4)Bounce time Operate: approx. 0.40ms; (5)Operating frequency Mechanical: 18000 operations/hour; (6)Operating frequency Electrical 1,800 operations/hour (under rated load); (7)Insulation resistance: 100MΩ min. (at 500 VDC); (8)Dielectric strength 4,000 VAC, 50/60 Hz for 1 minute between coil and contacts; (9)Impulse dielectric strength 10,000 VAC, 1.20 x 50μs (between coil and contacts); (10)Vibration Mechanical durability 10 to 55 Hz, 1.50 mm (0.06 in) double amplitude range; (11)Shock Mechanical durability 1,000 m/s2 (approx. 100 G); (12)Ambient temperature Operating: -25℃ to 55℃ (-13°to 131°F); (13)Ambient temperature Storage: -25℃ to 55℃ (-13°to 131°F); (14)Humidity: 35% to 85% RH; (15)Weight: 29g (1.02 oz).

Features

G4W-2214P-US-HP-DC24V features: (1)Impulse withstand voltage of 10000V between input and output (coil and contact); (2)Creepage distance of 10 mm (0.39 in) minimum between coil and contact meets VDE C/250; (3)Dielectric strength of 4,000 VAC minimum conforms to UL, CSA and IEC Class II; (4)International 2.5mm (0.10 in) terminal pitch; (5)Low power consumption (0.8W).
