Product Summary

The G5NB-1A-E-DC5V is a PCB Relay.

Parametrics

G5NB-1A-E-DC5V absolute maximum ratings: (1)Rated voltage: 5V; (2)Rated current: 40.0 mA; (3)Coil resistance: 125 Ω; (4)Must operate voltage: 75% of rated voltage (max.); (5)Must release voltage: 10% of rated voltage (min.); (6)Max. voltage Standard: 180% of rated voltage (at 23℃); (7)High-capacity: 170% of rated voltage (at 23℃); (8)Power consumption: Approx. 200 mW.

Features

G5NB-1A-E-DC5V features: (1)Max size 20.5L x 7.2 W x 15.3 W mm; (2)Standard models switch up to 3 A; High-capacity models switch up to 5 A (AC loads only); (3)Low power consumption (200 mW); (4)Semi-sealed and sealed types available; (5)UL recognized / CSA certified. VDE Approved; (6)RoHS Compliant.

Diagrams

G5NB-1A-E-DC5V Dimensions

G5NB-1A4 DC5
G5NB-1A4 DC5
Omron Electronics
General Purpose / Industrial Relays Power PCB Relay
Data Sheet
0-1: $1.22
1-25: $1.15
25-50: $1.12
50-100: $1.06
G5NB-1A-DC5
G5NB-1A-DC5
Omron Electronics
General Purpose / Industrial Relays Power PCB Relay 3A SPST-NO 5VDC
Data Sheet
0-1: $1.16
1-25: $1.04
25-50: $0.92
50-100: $0.83
G5NB-1A-DC24
G5NB-1A-DC24
Omron Electronics
General Purpose / Industrial Relays Power PCB Relay 3A SPST-NO 24VDC
Data Sheet
0-1: $1.15
1-25: $1.05
25-50: $0.95
50-100: $0.88
G5NB-1A-E DC18
G5NB-1A-E DC18
Omron Electronics
General Purpose / Industrial Relays SPST-NO 18VDC
Data Sheet
0-1: $1.10
1-25: $1.07
25-50: $1.03
50-100: $1.01
G5NB-1A4-E DC5
G5NB-1A4-E DC5

RELAY GENERAL PURPOSE SPST 5A 5V
Data Sheet
0-100: $1.17
G5NB-1A4-E DC24
G5NB-1A4-E DC24

RELAY GEN PURPOSE SPST 5A 24V
Data Sheet
0-100: $1.28
