LKS1aF-12V

LKS1AF-12V, 250mW, Slim Power Relay, REEL, 20cpm, 1,000 MΩ, 5 to 85% R.H.

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.40~0.80 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.40~0.80

PartNumber:: LKS1aF-12V

Brand:: Panasonic Semiconductor - Panasonic | Pack: DIP | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. loby chen's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-06-28

From Other Seller

Part Number:LKS1aF-12V
US $0.40 - 0.80
ECA1HHG4R7

US $10.00 - 10.00 / Piece
(0) Remove
A50L-0001-0175

US $100.00 - 100.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The LKS1aF-12V is a 250mW Slim Power Relay. The applications of the LKS1aF-12V include Audio visual equipment, Office equipment, and Home appliances.

Parametrics

LKS1aF-12V absolute maximum ratings: (1)Max. operating speed: 20cpm (at rated load); (2)Initial insulation resistance: Min. 1,000 MΩ(at 500V DC); (3)Initial breakdown voltage Between open contacts: 1000Vrms for 1 min.; (4)Between contact and coil: 4000Vrms for 1 min.; (5)Initial surge voltage between contact and coil: Min. 10000V; (6)Operate time (at nominal voltage) Approx. 7ms (at 20℃); (7)Release time (without diode) (at nominal voltage): Approx. 2ms(at 20℃); (8)Temperature rise (at 70℃): Max. 35℃ with nominal coil voltage and at 5A contact carrying current (resistance method); (9)Conditions for operation, transport and storage Ambient Temperature: –40℃ to +70℃; (10)Humidity: 5 to 85% R.H.

Features

LKS1aF-12V features: (1)High sensitivity: 250mW; (2)High insulation resistance between contact and coil; (3)High noise immunity realized by the card separation structure between contact and coil; (4)Popular terminal pitch in AV equipment field; (5)Space-saving slim type; (6)Conforms to the various safety standards.
