AXK5F26347YJ

AXK5F26347YJ, narrow-pitch connector, REEL, 60V, 90mΩ, 0.5A, 0.04g

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.12~0.32 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.12~0.32

PartNumber:: AXK5F26347YJ

Brand:: Panasonic Semiconductor - Panasonic | Pack: DIP | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. loby chen's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-05-20

From Other Seller

Part Number:AXK5F26347YJ
US $0.12 - 0.32
IRFP260N

US $1.30 - 4.20 / Piece
(0) Remove
SIL9030CTU

US $2.50 - 5.10 / Piece
(0) Remove
Quantity:

piece

Product Summary

The AXK5F26347YJ is a narrow-pitch connector for board-to-board connection. The applications of the AXK5F26347YJ include Compact portable devices “Cellular phones, DVC, Digital cameras, etc”.

Parametrics

AXK5F26347YJ absolute maximum ratings: (1) Rated current: 0.5A/contact (Max. 10A at total contacts); (2) Rated voltage: 60V AC/DC; (3) Breakdown voltage: 150V AC for 1 min.; (4) Insulation resistance: Min. 1,000MΩ (initial); (5) Contact resistance: Max. 90mΩ; (6) Composite insertion force: Max. 0.981N/contacts×contacts (initial); (7)Composite removal force: Min. 0.0588N/contacts×contacts; (8) Contact holding force (Socket contact): Min. 0.981N/contacts; (9) Ambient temperature: -55℃ to +85℃; (10) Storage temperature: -55℃ to +85℃ (product only), -40℃ to +50℃ (emboss packing); (11) Insertion and removal life: 50 times; (12) Unit weight: 20-contact type: Socket: 0.06g Header: 0.04g.

Features

AXK5F26347YJ features: (1) The connector is a two-piece structure and 0.5mm pitch; (2) Strong resistance to adverse environments. Utilizes construction for high contact reliability; (3) Simple locking structure Superior mating operation with click feel to indicate that mating is complete; (4) Mating length 0.55mm; (5) The lower connector bottom surface construction prevents contact and shorts between the PCB and metal terminals; (6) Automatic mounting inspection is facilitated by the gull-wing terminal shape which makes mounting verification easy; (7) Connectors for inspection available.
