RY210005

RY210005, miniature power PCB relay, 8 A, 220mW, 250 V, DIP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.50~0.95 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.50~0.95

PartNumber:: RY210005

Brand:: TE connectivity - TE | Pack: DIP | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. loby chen's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-06-27

From Other Seller

Part Number:RY210005
US $0.50 - 0.95
iphone5 data cable

US $4.00 - 5.00 / Piece
(0) Remove
SIL9030CTU

US $2.50 - 5.10 / Piece
(0) Remove
Quantity:

piece

Product Summary

The RY210005 is a miniature power PCB relay. Applications of the RY210005 are heating control, interface technology, domestic appliances, timers, temperature control.

Parametrics

RY210005 absolute maximum ratings: (1) Rated current: 8 A; (2) Rated voltage / max. Switching voltage AC: 250/400 VAC; (3) Maximum breaking capacity AC: 2000 VA; (4) Rated coil voltage range DC coil: 5 to 60 VDC; (5) Coil power DC coil typ.: 220mW; (6) Rated insulation voltage: 250 V; (7) Ambient temperature range: -40 to +70℃.

Features

RY210005 features: (1)1 pole 8 A, 1 CO or 1 NO or 1 NC contact; (2)Low component height 12.3 mm; (3)5 kV / 8 mm coil-contact; (4)Reinforced insulation (protection class II); (5)Pinnings: 3.2 and 5 mm; (6)reflow-solderable version; (7)Sockets with PCB-type terminals; (8)Especially suitable for resistive and inductive loads on NO and NC contacts; (9)Plastic materials according to IEC60335-1 (domestic appliances); (10)(not at reflow-solderable version).
